Platform Step Ladder
This platform ladder is economical yet strong, with a 150kg weight rating, a welded back leg and diagonal brace. The aluminium ladder folds down in one easy movement, and its light weight allows for easy handling and transportation.
Model Selection: YQZDT-800, YQZDT-1100, YQZDT-1400, YQZDT-1700, YQZDT-1900
● Sample available, platform ladder 3, 4, 5, 6, and 7ft. Models
● 150kg load rating in AS 1892.1
● MOQ 10pcs
● Warranty 1year
● OEM Service YES
● Shipping Air, Sea, Fast Express
● Download The Brochure

SEND INQUIRY

Description

Product Description


This platform ladder is economical yet strong, with a 150kg weight rating, a welded back leg and diagonal brace. The aluminium ladder gives a large safe work platform, much safer and user-friendly when working for longer periods or handling bulky items. One piece, smooth operation- simply folds out, and its light weight allows for easy handling and transportation. Optional spring loaded wheels attached to base to enable ladder to simply roll across the floor.




Product Features


◆ Wide and Comfortable, Safe and Convenient.

◆ Compact design, folds down for easy storage.

◆ Super wide platform, extra strong and durable.

◆ High handrail design, more comfortable to use.

◆ High strength aluminium construction provides more safety.


Product Specifications


ModelYQZDT-800YQZDT-1100YQZDT-1400YQZDT-1700YQZDT-1900


Steps34567
Handrail Height/A905mm905mm905mm905mm905mm
Platform Height/B815mm1095mm1380mm1660mm1945mm
Bottom Width/C605mm635mm665mm695mm725mm
Ladder Depth/D985mm1170mm1355mm1540mm1725mm
Ladder Length/E1880mm2185mm2480mm2780mm3080mm
Fold Thickness/F165mm165mm165mm165mm165mm
Weight8.5kg9.5kg11.3kg13kg14.6kg
20'' (pcs)181153132116100
40'' (pcs)425358309272235


Product Details
